China Excellent Quality and Reasonable Price Paddle Mixer for Dry Powder Blending

Product Description

Machine Description:

HOW IT WORKS:
PerMix PTP series Paddle Mixers provide the same mixing performance as a Plow Mixer (Ploughshare Mixer) but requires much less power consumption. Due to the less rotation speed of the paddles, the wearing of the mixing element for the Paddle is also less than the Plows. Besides, PerMix Paddle Mixers have a better performance dealing with the viscous/sticky materials, such as slurry, which is because the plough-shaped mixing elements tend to be wrapped by the viscous materials while the paddles don't.

Compared with the conventional Ribbon Blenders, Paddle Mixers are superior because they are able to mix the material in a more aggressive way while keeping the similar power consumption, due to the fact that the uniquely designed paddles are more pitched than ribbons in a Ribbon Blender and move more materials in a single turn.

Both Paddle and Plow are 'aggressive mixers' that are well qualified for high mixture ratio processes up to 1:1,000,000, which means the single sample of 1 ppm of a batch volume can still have the right mixture of ingredients.

LAB & PILOT MODELS:
PerMix designs the full range of paddle mixers, including the lab size (5L full) & pilot size (up to 45L full) models for Research & Development purpose. The small size machine is very helpful for customers when the ingredients for R&D are expensive, thus helping our customer to save their limited budget at the first stage. With the good performance of the lab & pilot mixer, it is easy to scale up for a medium size or even bigger one.

DESIGN WITH MULTI-CHOPPERS:
The installation of PerMix Multi-chopper in the basic PTP powder mixer enables the breaking down of agglomerates during the mixing process.

Together with the mixing element, the PerMix Multi-chopper removes lumps in the initial product, chops pasty adhesives and hinders the formation of agglomeration during the moisturizing of powdered substances. The PerMix Multi-chopper is operated independently by its own motor.

VACUUM MIXER DRYER:
With some special modification, the PerMix PTP series Paddle Mixer can be used as a multi-stage process vessel eliminating the need for additional specialist equipment. It can be used as a vacuum mixer dryer, mixer-granulator, de-aerator, reactor and cooler.

OPTIONAL FEATURES:
- Continuous operation
PerMix supplies mixers for continuous work when a large capacity per hour is needed for the same material. Continuous paddle mixers differ from batch paddle mixers in that the mass flow of the product is from the inlet of the container to the discharge at the opposite end.
- Heating/Cooling jacket
Jacketed trough for heating/cooling operation by steam, thermal oil, or water. ASME/PED certificate can be optional for high pressure operation.
- Feeding & Discharging
A variety of feeding & discharging methods can be selected by the customers. Discharging port can be by manual or pneumatic operation.
- Access door
Access doors can be designed for easy cleaning, inspection & maintenance.
- Drive system
Drive system by geared motor, cycloidal reducer, worm reducer, belt or chain transmission, etc.
- Extended machine bases
Discharge clearance of PerMix mixers are available according to customer's requirement, with extended machine bases, tubular frames, platform, etc.
- Spray nozzle
Liquid can be added into the powder by spray nozzles on a pipe which is installed on the top of the mixing trough. The necessary pump and tank can also be provided by PerMix.

APPLICATIONS:
- Foods
Baby Food, Cereals, Coffee, Decor Sugar, Diet Foods, Filling Ingredients, Flour Mixes, Frozen Vegetables, Fruit Mixes, Fruit Purees, Granola, Infant Formula, Juice Powder, Seasonings, Soluble Cocoa Drinks, Starch, Sugars, Tea Mixes
- Nutrition
Enzymes, Lecithin Powder, Mineral Substances, Nutrition Supplements, Protein, Sports Nutrition, Vitamin Mixes, Whey Powder
- Cosmetics
Coloring Powder, Dispersing Agent, Kaolin Clay, Mask Powder, Mica Flour, Surface Active Agent, Talcum Powder, Titanium Dioxide
- Chemicals
Adhesives, Carbon Black, Dyestuff, Electrode Mass, Fly Ashes, Fungicides, Peat Moss Mixes, Pesticides, Pharmaceuticals, Pigments, Plastic Additives, Resins, Solid Lubricants
- Building Materials
Brick Facings, Dry Mortar Mixes, Flooring Materials, Gypsum, Road Lining Materials, Wall Plasters

Model	Total capacity (liter)	Working capacity (liter)	*Power () (kW)**	Speed (rpm)	L1 (mm)	L (mm)	W (mm)	H1 () (mm)**	H ()* (mm)
PTP-5L	5	3	1.1	0-582	180	800	500	-	-
PTP-10L	10	7	1.1	0-582	200	900	500	-	-
PTP-45	45	30	0.75	81	480	900	550	450	950
PTP-70	70	45	0.75	69	580	1,050	600	450	970
PTP-100	100	70	1.1	60	660	1,100	610	450	1,020
PTP-200	200	140	1.5	53	890	1,400	730	500	1,180
PTP-300	300	210	2.2	51	970	1,550	850	500	1,300
PTP-500	500	350	4	45	1,250	2,000	950	500	1,400
PTP-750	750	500	5.5	45	1,500	2,250	1,100	600	1,600
PTP-1000	1,000	700	7.5	33	1,900	2,600	1,150	600	1,800
PTP-1500	1,500	1,000	11	28	2,110	3,200	1,200	600	2,000
PTP-2000	2,000	1,400	15	25	2,110	3,500	1,350	600	2,200
PTP-3000	3,000	2,100	22	23	3,000	4,100	1,500	800	2,400
PTP-4000	4,000	2,800	30	17	3,000	4,200	1,550	800	2,600
PTP-5000	5,000	3,500	37	17	3,000	4,300	1,620	800	2,800

1. PTP-L: laboratory size
2. (*) (**) (***): Changes are available according to the customer's request.
3. All specifications and illustrations are as accurate as is reasonably possible, but they are not binding.
4. PerMix reserves the right to modify the design without notice.

Excellent Quality and Reasonable Price Paddle Mixer for Dry Powder Blending

Q: What is your price level compared with European suppliers and local Chinese suppliers?
A: Depending on the machine type and size, our price level is 30%-60% less than the European suppliers and 5-15% higher than the big local suppliers.

Q: Are you able to provide tailor-made design and production for the mixers?
A: Yes, in fact more than half of our mixers are tailor made, which is one of our strong points.

Q: Are you able to design and produce other processing equipment?
A: We are open to discuss about it.

Q: Can you provide machines to OEM customers, meaning to label their brands on the machines.
A: Yes we are doing it a lot. We have several OEM partners in the USA.

Q: Do you have agent network out of China?
A: Yes we do have agents but only in some countries, for example in USA, Germany, Poland, Spain, Denmark, Turkey, Argentina, etc. We are still looking for more agents because we believe to work with agents is the best way to do business.

Q: What is your delivery lead time of the mixing equipment.
A: Depending on the size and level of customization, but usually it is from 6-14 weeks.

Q: How do you pack and ship the mixing machines?
A: For machines don't require full container loading, we will pack them in wooden case. For FCL (full container loading) shipment, we will just wrap the machines in plastic films and fix them in the container. The shipment can be either by air or by sea.
