Cw-500 Stirring Double Cone Mixer
Cw-500 Stirring Double Cone MixerModel CW-500Barrel Volume(L) 500Mixing motor 3Stirring motor 2.2Mixing rotary speed (rpm/min) 20Stirring rotary speed(rpm/min) 60Overall dimension 2320*950*1920Features:This machine can rapidly mix such materials as easy clot and with certain water content, having fa......
Send Inquiry
Product Description
Cw-500 Stirring Double Cone MixerModel CW-500
Barrel Volume(L) 500
Mixing motor 3
Stirring motor 2.2
Mixing rotary speed (rpm/min) 20
Stirring rotary speed(rpm/min) 60
Overall dimension 2320*950*1920
Features:
This machine can rapidly mix such materials as easy clot and with certain water content, having fast mixing speed and good mixing effect. Inner of this machine is of new type sealing structure, during mixing, it is free of pollution, with simple structure and convenient operation and maintenance.
Main Application:
Our company develops CW series stirring mixer under absorption of foreign new technology, based on W series double cone mixer, this machine adds stirring unit, which can be used for material mixing in industries as pharmacy, foodstuff, chemical industries as pharmacy, foodstuff, chemical industry and feedstuff etc.
Technical Parameter:
| Model | Barrel Volume(L) | Mixing Motor | Stirring motor | Mixing rotary speed (rpm/min) | Stirring rotary speed(rpm/min) | Overall dimension |
| CW-50 | 50 | 1.1 | 0.75 | 20 | 60 | 1500*450*1200 |
| CW-100 | 100 | 1.5 | 1.1 | 20 | 60 | 1550*550*13500 |
| CW-200 | 200 | 2.2 | 1.1 | 20 | 60 | 1800*700*1500 |
| CW-300 | 300 | 2.2 | 1.1 | 20 | 60 | 2100*760*1760 |
| CW-500 | 500 | 3 | 2.2 | 20 | 60 | 2320*950*1920 |
| CW-1000 | 1000 | 5.5 | 2.2 | 10 | 40 | 2450*1050*2500 |
| CW-1500 | 1500 | 7.5 | 4 | 10 | 40 | 2900*1300*2700 |
| CW-2000 | 2000 | 7.5 | 4 | 8 | 30 | 3000*1400*3100 |
| CW-2500 | 2500 | 11 | 5.5 | 6 | 20 | 3600*1400*3200 |
| CW-3000 | 3000 | 11 | 5.5 | 6 | 20 | 4000*1500*3500 |
| CW-4000 | 4000 | 15 | 5.5 | 6 | 20 | 4800×1300×3800 |
| CW-5000 | 5000 | 15 | 7.5 | 5 | 20 | 5400×1300×4000 |
| CW-6000 | 6000 | 17.5 | 7.5 | 5 | 20 | 5650×1300×4380 |
