                            Mobile Stone Crusher and Screening Plant
                            • Mobile Stone Crusher and Screening PlantMobile Stone Crusher and Screening Plant
                            • Mobile Stone Crusher and Screening PlantMobile Stone Crusher and Screening Plant
                            • Mobile Stone Crusher and Screening PlantMobile Stone Crusher and Screening Plant
                            • Mobile Stone Crusher and Screening PlantMobile Stone Crusher and Screening Plant

                            Mobile Stone Crusher and Screening Plant

                            Featuresportable impact crushing plant is not limited by the crushing place, and reduces high material transportation cost. The portable impact crushing plant can crush materials on site or work nearly. The Portable Impact Crushing Plant is widely used in the industry of mining, metallurgy, building......

                            Send Inquiry

                            Product Description

                            Features

                            portable impact crushing plant is not limited by the crushing place, and reduces high material transportation cost. The portable impact crushing plant can crush materials on site or work nearly. The Portable Impact Crushing Plant is widely used in the industry of mining, metallurgy, building materials, traffic, and water conservancy facilities and so on.

                            Benefits

                            • Move easily;
                            • Compact structure and simple operation;
                            • Save the cost;
                            •  Wide application.
                            • Good performance and convenient maintenance.
                            • Flexible configuration.


                            The quality of the end product

                            The Portable Impact Crushing Plant  are used for soft to medium-hard natural stone and for the reprocessing of residual construction materials. What is important today, in addition to the quality of the end product, is environmental and cost awareness, availability and a wide field of application. The Portable Impact Crushing Plant unite all these requirements. In the process, they guarantee an end product that represents the high demands of concrete and asphalt granulation standards with regard to grain shape, grain distribution and cleanliness.

                            Flexible and tough

                            The Portable Impact Crushing Plant are specially designed to accept large feed sizes and can be used as primary or secondary crushers in certain applications.They are ideal for processing soft to medium-hard materials such as natural stone in mining and quarrying applications as well as construction and demolition materials.

                            Specifications
                             PE SERIES
                             Model
                            Shaker model
                                 Impact crusher    Belt conveyor    Tyre configuration    Capacity  (t/h)    Power  (kW)    The maximum Feeding size (mm)    Dimebsions  (L×W×H) (mm)      Weigth
                              (t)
                            KL3S1548F1010    3YA1548    PF1010    B500×7M    Double axles    30-100    70-90    350    12500×2800×6000    42
                            KL3S1854F1210    3YA1854    PF1210    B650×7M    Double axles    56-120    128.5-150.5    350    12500×3000×6500    46
                            KL3S1860F1214    3YA1860    PF1214    B650×8M    Three axles    65-180    154-190    350    13500×3000×6500    51
                            KL3S2160F1315    3YA2160    PF1315    B800×8M    Three axles    81-220    210-297    350    14000×3200×6800    57
